Eutectic Die Attach Paper

Optimizing High Power GaN Device Performance With Eutectic Die Attach

StratEdge has introduced a line of packages for the extreme demands of GaN devices and developed a eutectic die attach process that produces extremely thin, low-void bond lines between the device and package heat sink. We also provide the same service for die-on-tab. Click to learn more about the 6 micron thick, AuSn die attach process that produces >96% coverage.

Make an Appointment—Connect with StratEdge

About StratEdge

StratEdge Corporation, founded in 1992, designs, manufactures, and provides assembly services for a complete line of high-performance semiconductor packages operating from DC to 63+ GHz for the high-speed digital, mixed signal, broadband wireless, satellite, point-to-point/multipoint, VSAT, and test and measurement industries. StratEdge offers post-fired ceramic, low cost molded ceramic, and ceramic QFN packages, and specializes in packages for extremely demanding gallium arsenide (GaAs) and gallium nitride (GaN) devices. All packages are lead-free and most meet RoHS and WEEE standards. StratEdge is an ISO 9001:2015 certified facility located in Santee, California, near San Diego.

Our packages are known for:

  • Very low electrical losses over wide frequencies
  • Superior electrical, mechanical, and thermal performance
  • Non-shrinking post-fired hardened ceramic composition
  • High thermal conductivity bases
  • Hermetic surface mount and drop-in designs

StratEdge customers experience:

  • Very high device performance
  • Low NREs, low risk, and fast time-to-market
  • Wide range of standard sizes and pin counts
  • Complete assembly and sealing solutions
  • The best personal attention and service in the industry

Our Services

Assembly Services

StratEdge Assembly Services packages a wide variety of compound semiconductors and silicon in our new ISO 9001:2015 facility in Santee, California (near San Diego). We have a Class 1000 cleanroom, including Class 100 work areas with ESD control for performing sensitive operations, which is fully equipped with the most modern assembly equipment. StratEdge can customize packages and assembly services for your specific requirements. Read More..


StratEdge high performance semiconductor packages operate from DC-63+GHz for the high speed digital (OC-48, OC-192, OC-768), mixed signal, broadband wireless, satellite, point-to-point and point-to-multipoint, VSAT, and test and measurement industries. Read More..

Customized Packages

StratEdge offers customers packages in leaded and leadless drop-in formats, leaded and leadless surface mount formats, and specialty high power and high speed digital designs. In addition to the hundreds of standard package outlines available, StratEdge offers custom design services at a fraction of the cost of co-fired ceramic packaging. Please contact the factory for additional details.

StratEdge Corporation Packages Used in Mars Rovers

Did you know that StratEdge packages are used in generations of the Mars Rovers?

The Mars Exploration Rovers Spirit and Opportunity were sent to explore the surface of Mars in 2003, and now the most recent Perseverance Rover. To transmit signals and information back to Earth, the rovers were equipped with the power amplifier packages from StratEdge. The amplifier system was designed to protect the gallium arsenide monolithic microwave integrated circuits (MMICs) to ensure true signal integrity. All signals that are transmitted go into the StratEdge package through the chip, and back out the package.Read More
