Metal
Flatpack Design
Guide
If
you would like more information or an estimate, please print
out the following diagram, write in your specifications,
and fax to us at 858-228-9728.
| Material:
|
Plating:
|
| No.
of Leads:
|
Leads
on
Sides |
| I.D.
Bead: Pin #:
|
Ground
Pins: Pin #
|
|
Tolerance:
+/- 0.05 Unless Otherwise Indicated.
|
|
NOTE:
Standard Metal Flatpacks are uniwall construction.
Two piece construction is available upon request.
|
